Laboratory small coater detection principle
The DP24772 automatic film applicator is designed to create consistent and traceable thin films, offering a significant improvement over manual methods that often result in uneven coatings, especially when different operators are involved. This inconsistency can make sample comparisons unreliable or even impossible. The DP24772 ensures high reproducibility by precisely controlling key factors such as shear rate and the weight applied during coating. It uses a wire rod or applicator that moves back and forth at a set speed, ensuring uniform application of the film. The test paper is securely held on a vacuum cup, and since both the shear rate and the applied force remain constant throughout the process, the quality and consistency of the coated film are greatly enhanced.
As an advanced automatic film coating system, the DP24772 integrates the latest technology from similar foreign equipment. Compared to other domestic models, it offers several unique advantages:
- â—† Wide range stepless speed control: 5~150mm/s
- â—† High-precision ball screw combined with a DC brushless motor for smoother film application
- â—† External vacuum pump design to eliminate vibration issues commonly found in machines with built-in pumps
- â—† Ergonomically designed coating stent for easy operation and optional increased load capacity
- â—† High flatness and surface hardness vacuum suction platform for stable performance
- â—† Adjustable starting point for coating to accommodate various substrate sizes
- â—† Four customizable coating distances available
- â—† Compatible with multiple types of film applicators and coating rods
Key technical specifications include:
- ■Vacuum cup size: 360 mm × 250 mm
- â– Coating length: up to 25 cm (four different distances available)
- â– Coating speed: 0 ~ 150mm/s, with continuous speed adjustment
- â– Coating stent weight: 1.5KG (optional weights: 2KG, 2.5KG)
- â– Total power: 300W
- â– Power supply: 220V; 50/60Hz
- ■Dimensions: 500 × 342 × 272 mm (L×W×H, excluding vacuum pump)
- â– Weight: 25KG
Whether you're working in a research lab, quality control, or production environment, the DP24772 provides reliable, repeatable, and professional-grade film coating solutions. Its user-friendly design, precise control, and advanced features make it an ideal choice for laboratories that require accuracy and efficiency in their coating processes.
